WL-MMT-20 Sand Filter System+submersible pump + SQ30 ระบบเกลือ ,สำหรับสระไม่เกิน ≤160 m³
Attribute:
SKU : WL-MMT-20
BCG700 sand filter + HLLF200M circulation pump + HLLF300M Massage pump + submersible pump + SQ30 salt chlorine generator, Flow Rate 20 (m³/h) ,Pool volume ≤160 m³ Outline size 1320*1340*985 mm.(update 29/04/2024)
Categories : Filtration unit , Salt Chlorinator ,
Brand : laswim
Share
WL-MMT
1. The progressive filtration unit adopts professional sand filter, high efficiency pump and salt-chlorine generator, 3HP massage pump and submersible pump.
2. 3HP massage pump makes the filtration unit more powerful
3. Equipped with submersible pump, avoiding the security risk that caused by accumulated water in tank.
4. Equipped with salt-chlorine generator, the most effective and high-tech equipments.
WL-MMT parameter
| Model | Horsepower (HP) | Voltage (V) | Flow Rate (m³/h) | Filter Area (m2) | Pool volume (m³) | Outline size (mm) |
| WL-MMT-8 | 0.75 | 220-240 | 8 | 0.16 | ≤64 | 1320*1340*985 |
| WL-MMT-12 | 1 | 12 | 0.23 | ≤92 | ||
| WL-MMT-16 | 1.5 | 16 | 0.32 | ≤128 | ||
| WL-MMT-20 | 2 | 20 | 0.4 | ≤160 | 1550*1560*1135 | |
| WL-MMT-25 | 25 | 0.5 | ≤220 |
WL-MMT Specification
| Model | Main parts |
| WL-MMT-8 | BCG450 sand filter + HLLF075M circulation pump + HLLF300M Massage pump + submersible pump + EC8 salt chlorine generator |
| WL-MMT-12 | BCG500 sand filter + HLLF100M circulation pump + HLLF300M Massage pump + submersible pump + EC12 salt chlorine generator |
| WL-MMT-16 | BCG650 sand filter + HLLF150M circulation pump + HLLF300M Massage pump + submersible pump + EC16 salt chlorine generator |
| WL-MMT-20 | BCG700 sand filter + HLLF200M circulation pump + HLLF300M Massage pump + submersible pump + SQ30 salt chlorine generator |
| WL-MMT-25 | BCG800 sand filter + HLLF200M circulation pump + HLLF300M Massage pump + submersible pump + SQ40 salt chlorine generator |
